ExactFlat Stress colors

I had a quick question regarding the black color in the stress highlight, sometimes I get patches of it and i understand the other colors but what is the mean on the black stress color?

we are talking about this plug-in ?

maybe contact their support or send them a link to this topic ?



Hi @Tommy804,

The black spots represents areas of sag (excess material). It’s difficult to say from the screenshot, but this sag may be a result of FEA model preparation and meshing.

Feel free to contact us at support@exactflat.com and we can help you reduce the sag on your pattern.

Thank-you for the tag @Tom_P!
