Tiling Geometry Grasshopper

Grasshopper
1

Tile%20Geometry%20
Tile Geometry .jpg526×530 64.1 KB

I am new to Rhino and Grasshopper and have been assigned to make a geometric tile and want to achieve something similar to the shape and patterns I posted above using grasshopper.

Any help will be appreciated thanks.

2

The color scheme is up to you.

tiling_2019Nov11a
tiling_2019Nov11a.png1117×421 34.4 KB

tiling_2019Nov11a.gh (19.8 KB)

3

Thank you this is very helpful!

4

What is the command for the 0.50?

5

‘Curve | Analysis | Point On Curve’. Hold CTRL-ALT and mouse down on any component to see where it came from.

Here’s a simplistic variant of the ‘Colorful’ cluster, adding Jitter:

tiling_2019Nov11b
tiling_2019Nov11b1154×421 36.2 KB

tiling_2019Nov11b.gh (21.8 KB)

P.S. Looking more closely, I see I missed a detail. All the vertical lines in your image are missing the gap that appears on the horizontal and angled lines.

6

Thank you for that info and yes the vertical lines are missing the gaps, do you mind showing me?

7

I took a look but don’t see a quick fix, sorry. For one thing, the base plane needs to be rotated 90 degrees to get the horizontal lines/gaps before trying to suppress the vertical gaps:

tiling_2019Nov11b2
tiling_2019Nov11b2992×527 29.1 KB
